Iron-based Perovskite Material La0.25M0.75FeO3-δ (M= Ca, Sr, Ba): Preparation and Performance as Cathode for Solid Oxide Fuel Cells

doi:10.15541/jim20240500

Abstract

Abstract: Solid Oxide Fuel Cell (SOFC) performance is mainly constrained by the cathode's oxygen reduction reaction (ORR), which is crucial for overall cell efficiency. This study synthesized La_0.25M_0.75FeO_3-_δ (M=Ca, Sr, Ba, abbreviated as LCF, LSF, LBF) perovskite cathodes based on tolerance factors and structural design to examine the effects of Ba, Sr, and Ca doping on electrochemical performance. Different alkaline earth elements have a significant effect on the crystal structure. LBF is Pm-3m cubic phase, LSF is R-3c rhombohedral phase, and LCF is a composite phase of P21ma orthogonal and Pcmn rhombohedral. The difference of crystal structure also leads to various thermal expansion coefficient (TEC) and electrical conductivity. LCF possesses the smallest TEC (1.38 × 10^-56 K^-1), while LSF possesses the highest conductivity, which reaches 404.4 S·cm^-1 at 550 °C. All of three Fe-based cathodes exhibit excellent stability in air and CO₂ atmospheres, as well as chemical compatibility with electrolytes. In addition, different alkaline earth elements also affect the catalytic activity of the material. LSF and LBF have low area specific resistance (ASR). At 800 °C, their ASR are only 0.022 and 0.027 Ω·cm² which are better than 0.351 Ω·cm² of LCF. The higher oxygen reduction activity is attributed to its crystal structure, oxygen adsorption and dissociation ability. In view of the advantages and disadvantages of Ba²⁺, Sr²⁺ and Ca²⁺ in cathode performance, medium/high-entropy design can be effectively introduced in A-site in the future to give full play to their respective advantages to obtain SOFC cathode with excellent comprehensive performance.

Key words: solid oxide fuel cell, perovskite, cobalt-free cathode, electrochemical performance

CLC Number:

TM911

YANG Hengqiang, ZHANG Xinyue, MA Yichu, ZHOU Qingjun. Iron-based Perovskite Material La_0.25M_0.75FeO_3-_δ (M= Ca, Sr, Ba): Preparation and Performance as Cathode for Solid Oxide Fuel Cells[J]. Journal of Inorganic Materials, DOI: 10.15541/jim20240500.

References

[1] NDUBUISI A, ABOUALI S, SINGH K, et al. Recent advances, practical challenges, and perspectives of intermediate temperature solid oxide fuel cell cathodes. Journal of Materials Chemistry A, 2022, 10(5): 2196.
[2] CHEN Z, JIN F, LI M,et al., Double perovskite Sr₂CoFeO₅+_δ: preparation and performance as cathode material for intermediate-temperature solid oxide fuel cells. Journal of Inorganic Materials, 2024, 39(3): 337.
[3] SAMREEN A, ALI M S, HUZAIFA M,et al. Advancements in perovskite-based cathode materials for solid oxide fuel cells: a comprehensive review. The Chemical Record, 2023, 24(1): e202300247.
[4] SONG Y, CHEN Y, XU M, et al. A cobalt-free multi-phase nanocomposite as near-ideal cathode of intermediate-temperature solid oxide fuel cells developed by smart self-assembly. Advanced Materials, 2020, 32(8): 1906979.
[5] WANG J, ZHANG D, LIU T, et al. Self-assembled FeRu bimetallic nanocatalysts for efficient and durable mutual CO-CO₂ conversion in a reversible solid oxide electrochemical cell. Science China Materials, 2024, 67(5): 1471.
[6] PAN J, MA G, SONG L, et al. High stability/catalytic activity Co-based perovskite as SOFC anode: in-situ preparation by fuel reducing method. Journal of Inorganic Materials, 2024, 39(8):911.
[7] ZHANG B, ZHANG S, HAN H,et al. Cobalt-free double perovskite oxide as a promising cathode for solid oxide fuel cells. ACS Applied Materials & Interfaces, 2023, 15(6): 8253.
[8] CRUMLIN E J, AHN S J, LEE D,et al. Oxygen electrocatalysis on epitaxial La_0.6Sr_0.4CoO₃-_δ perovskite thin films for solid oxide fuel cells. Journal of The Electrochemical Society, 2012, 159(7): F219.
[9] ZHOU W, RAN R, SHAO Z.Progress in understanding and development of Ba_0.5Sr_0.5Co_0.8Fe_0.2O₃-_δ-based cathodes for intermediate-temperature solid-oxide fuel cells. a review. Journal of Power Sources, 2009, 192(2): 231.
[10] QI S, CHEN Y, LIN Z,et al. PrSr₃Fe₃O₁₀-_δ as cobalt-free cathode for intermediate-temperature solid oxide fuel cell. Materials Letters, 2020, 279: 128489.
[11] ZHOU Q, CHENG Y, LI W,et al. Investigation of cobalt-free perovskite Sr₂FeTi_0.75Mo_0.25O₆-_δ as new cathode for solid oxide fuel cells. Materials Research Bulletin, 2016, 74: 129.
[12] ZHOU Q, CHEN L, CHENG Y, et al. Cobalt-free quintuple perovskite Sm_1.875Ba_3.125Fe₅O₁₅-_δ as a novel cathode for intermediate temperature solid oxide fuel cells. Ceramics International, 2016, 42(8): 10469.
[13] WANG C, MIAO H, ZHANG X, et al. On Fe-based perovskite electrodes for symmetrical reversible solid oxide cells - a review. Journal of Power Sources, 2024, 596: 234112.
[14] ZHOU Q, XU L, GUO Y, et al. La_0.6Sr_0.4Fe_0.8Cu_0.2O₃-_δ perovskite oxide as cathode for IT-SOFC. International Journal of Hydrogen Energy, 2012, 37(16): 11963.
[15] HOU SEN, AGUADERO A, ALONSO J A, et al. Fe-based perovskites as electrodes for intermediate-temperature solid oxide fuel cells. Journal of Power Sources, 2011, 196(13): 5478.
[16] PETRIC A, HUANG P, TIETZ F.Evaluation of La-Sr-Co-Fe-O perovskites for solid oxide fuel cells and gas separation membranes.Solid State Ionics, 2000, 135: 719.
[17] GOLDSCHMIDT V M.Die Gesetze der Krystallochemie.Die Naturwissenschaften, 1926, 14(21): 477.
[18] WANG Y, QI H,et al. Tuning the ORR catalytic activity of LaFeO₃-_δ-based perovskite cathode for solid oxide fuel cells by doping with alkaline-earth metal elements. Ceramics International, 2024, 50(3): 5818.
[19] ECIJA A, VIDAL K, LARRAÑAGA A, et al. Characterization of Ln_0.5M_0.5FeO₃-_δ (Ln=La, Nd, Sm; M=Ba, Sr) perovskites as SOFC cathodes. Solid State Ionics, 2011, 201(1): 35.
[20] HUNG M H, RAO M V M, TSAI D S. Microstructures and electrical properties of calcium substituted LaFeO₃ as SOFC cathode.Materials Chemistry and Physics, 2007, 101(2/3): 297.
[21] ZHOU Q, ZHANG X, WANG Y,et al. A thermal-expansion offset to cobalt-based cathode materials for solid oxide fuel cells. Next Energy, 2024, 5: 100168.
[22] HROVAT M, HOLC J, KOLAR D.Thick film ruthenium oxide/yttria-stabilized zirconia-based cathode material for solid oxide fuel cells.Solid State Ionics, 1994, 68: 99.
[23] WANG J Q, ZHOU D F, GAO J Q, et al. Effect of A/B‐site non‐stoichiometry on the structure and properties of La_0.9Sr_0.1Ga_0.9Mg_0.1O₃-_δ Solid electrolyte in intermediate‐temperature solid oxide fuel cells. ChemElectroChem, 2018, 5(4): 665.
[24] BAI J, ZHOU D, ZHU X,et al. In-situ segregation of A-site defect (La_0.6Sr_0.4)_0.90Co_0.2Fe_0.8O₃-_δ to form a high-performance solid oxide fuel cell cathode material with heterostructure. Ceramics International, 2023, 49(4): 5687.
[25] PEI Y, WANG H, GONG J,et al. Co and Hf co-doped BaFeO₃ cathode with obviously enhanced catalytic activity and CO₂ tolerance for solid oxide fuel cell. International Journal of Hydrogen Energy, 2022, 47(89): 37945.
[26] DONG F, CHEN D, CHEN Y,et al. La-doped BaFeO₃-_δ perovskite as a cobalt-free oxygen reduction electrode for solid oxide fuel cells with oxygen-ion conducting electrolyte. Journal of Materials Chemistry, 2012, 22: 15071.
[27] WEI B, LU Z, HUANG X, et al. Synthesis, electrical and electrochemical properties of Ba_0.5Sr_0.5Zn_0.2Fe_0.8O₃-_δ perovskite oxide for IT-SOFC cathode. Journal of Power Sources, 2008, 176: 1.
[28] UNGER L S, NIEDRIG C, WAGNER S F,et al. Yttrium doping of Ba_0.5Sr_0.5Co_0.8Fe_0.2O₃-_δ part I: influence on oxygen permeation, electrical properties, reductive stability, and lattice parameters. Journal of the European Ceramic Society, 2018, 38(5): 2378.
[29] ZHANG W, ZHANG L, GUAN K,et al. Effective promotion of oxygen reduction activity by rare earth doping in simple perovskite cathodes for intermediate-temperature solid oxide fuel cells. Journal of Power Sources, 2020, 446: 227360.
[30] MOHSIN M, YOUSAF A, RAZA R, et al. Highly conducting perovskite structured (M-SrCoFe-O₃-_δ, M = Ce, Ba) cathode for solid oxide fuel cell. Journal of Alloys and Compounds, 2019, 791: 248.
[31] ZHANG T, CHEN H, XIAO C,et al. Comparative investigation of composition, microstructure and property influences on electrocatalysis of two representative cathodes: BaCo_0.4Fe_0.4Zr_0.1Y_0.1O₃-_δ versus Ba_0.5Sr_0.5Co_0.8Fe_0.2O₃-_δ. Journal of Electroanalytical Chemistry, 2024, 975: 118735.
[32] LUO Y, ZHANG D, LIU T, et al. In situ exsolution of quaternary alloy nanoparticles for CO₂ ‐CO mutual conversion using reversible solid oxide cells. Advanced Functional Materials, 2024, 34(40): 2403922.
[33] ZHOU Q, SHI Y, HU J, et al. Preparation, characterization, and electrochemical properties of YBaCo_3.4Al_0.3Ga_0.3O₇+_δ and YBaCo_3.2Al_0.4Ga_0.4O₇+_δ cathodes for IT-SOFCs. Ceramics International, 2014, 40(8): 13481.
[34] SUN Y, YAO C, ZHANG Z,et al. Non-metal doping enhsances oxygen reduction kinetics and CO₂ tolerance of SrFeO₃-_δ perovskite as high-performance cathodes for solid oxide fuel cells. Fuel, 2024, 378: 132917.
[35] GOU Y, LI G, REN R, et al. Pr-doping motivating the phase transformation of the BaFeO₃-_δ perovskite as a high-performance solid oxide fuel cell cathode. ACS Applied Materials & Interfaces, 2021, 13: 20174.
