面向紫光激发LED的Eu2+/Ce3+掺杂荧光粉数据库

doi:10.15541/jim20250116

摘要/Abstract

摘要： 商用荧光转换白光LED(pc-WLEDs)激发源为蓝光LED,这一方案存在两大固有缺陷：蓝光危害和低显色指数。针对上述技术瓶颈,学界提出了以400~420 nm波段紫光LED作为激发源的方案。然而,能够被紫光高效激发的荧光粉目前仍处于开发阶段。为探索新型紫光激发荧光粉,本研究基于大型语言模型构建了一个Eu²⁺和Ce³⁺掺杂荧光粉的数据库。通过系统分析9,551篇研究论文,本课题组提取并验证了822组荧光粉数据,涵盖了元素组成、晶体结构及激发/发射波长等关键参数。研究结果表明：相比于Ce³⁺掺杂体系,Eu²⁺掺杂荧光粉在紫光激发和红光发射上更具优势,特别是氮化物和硫化物基质中的Eu²⁺掺杂体系,在紫光激发上更有潜力。该数据库的建立为后续利用人工智能开发新型pc-WLEDs荧光粉提供了重要的数据支持。

关键词: 荧光粉, 紫光LED, 大语言模型, 数据库

Abstract: Commercial phosphor-converted white LEDs (pc-WLEDs) face two inherent limitations, namely, blue light hazard and low color rendering index, due to the use of blue LEDs as excitation source. To address these challenges, violet LEDs are proposed as an alternative solution. Currently, phosphors that can be efficiently excited by violet light (with wavelength from 400 to 420 nm) remain under development. In this study, we utilize large language models to construct a comprehensive database of Eu²⁺ and Ce³⁺ doped phosphors for discovering novel violet-excited phosphors. A total of 822 phosphor data entries, including elemental compositions, crystal structures, and excitation/emission wavelengths, are extracted and validated from 9,551 research papers. Compared with Ce³⁺ doped phosphors, the Eu²⁺ are in general more suited for violet-excited phosphors, as well as red-emitting phosphors. In particular, Eu²⁺ doped nitrides and sulfides are worth of exploration for violet-excited phosphors. This database is expected to be useful in future development of phosphors for pc-WLEDs based on artificial intelligence methods.

Key words: phosphor, violet LED, large language model, database

中图分类号:

TB34

周子淳, 张翔, 明辰, 孙宜阳. 面向紫光激发LED的Eu²⁺/Ce³⁺掺杂荧光粉数据库[J]. 无机材料学报, DOI: 10.15541/jim20250116.

ZHOU Zichun, ZHANG Xiang, MING Chen, SUN Yiyang. Database of Eu²⁺ and Ce³⁺ Doped Phosphors for Development of Violet-light Excited White LEDs[J]. Journal of Inorganic Materials, DOI: 10.15541/jim20250116.

参考文献

[1] NAKAMURA S, MUKAI T, SENOH M.High-brightness InGaN/AlGaN double-heterostructure blue-green-light-emitting diodes. Journal of Applied Physics, 1994, 76(12): 8189.
[2] LI G, TIAN Y, ZHAO Y, et al.Recent progress in luminescence tuning of Ce³+ and Eu²+ activated phosphors for pc-wleds. Chemical Society Reviews, 2015, 44(23): 8688.
[3] WANG L, XIE R-J, SUEHIRO T, et al.Down-conversion nitride materials for solid state lighting: recent advances and perspectives. Chemical Reviews, 2018, 118(4): 1951.
[4] GEORGE N C, DENAULT K A, SESHADRI R.Phosphors for solid-state white lighting. Annual Review of Materials Research, 2013, 43(1): 481.
[5] DORENBOS P.Energy of the first 4f⁷→4f⁶5d transition of Eu²+ in inorganic compounds. Journal of Luminescence, 2003, 104(4): 239.
[6] LAI S, ZHAO M, ZHAO Y, et al.Eu²+ doping concentration-induced site-selective occupation and photoluminescence tuning in KSrScSi₂ O₇?:Eu²+ phosphor. ACS Materials Au, 2022, 2(3): 374.
[7] QIN X, LIU X, HUANG W, et al.Lanthanide-activated phosphors based on 4f-5d optical transitions: theoretical and experimental aspects. Chemical Reviews, 2017, 117(5): 4488.
[8] MUELLER-MACH R, MUELLER G O, KRAMES M R, et al.High-power phosphor-converted light-emitting diodes based on iii-nitrides. IEEE Journal of Selected Topics in Quantum Electronics, 2002, 8(2): 339.
[9] STEIGERWALD D A, BHAT J C, COLLINS D, et al.Illumination with solid state lighting technology. IEEE Journal of Selected Topics in Quantum Electronics, 2002, 8(2): 310.
[10] NAIR G B, SWART H C, DHOBLE S J.A review on the advancements in phosphor-converted light emitting diodes (pc-leds): phosphor synthesis, device fabrication and characterization. Progress in Materials Science, 2020, 109: 100622.
[11] BELLIA L, BISEGNA F, SPADA G.Lighting in indoor environments: visual and non-visual effects of light sources with different spectral power distributions. Building and Environment, 2011, 46(10): 1984.
[12] CAJOCHEN C, MÜNCH M, KOBIALKA S, et al. High sensitivity of human melatonin, alertness, thermoregulation, and heart rate to short wavelength light. The Journal of Clinical Endocrinology & Metabolism, 2005, 90(3): 1311.
[13] PAULEY S M.Lighting for the human circadian clock: recent research indicates that lighting has become a public health issue. Medical Hypotheses, 2004, 63(4): 588.
[14] YE S, XIAO F, PAN Y X, et al.Phosphors in phosphor-converted white light-emitting diodes: recent advances in materials, techniques and properties. Materials Science and Engineering: R: Reports, 2010, 71(1): 1.
[15] DORENBOS P.A review on how lanthanide impurity levels change with chemistry and structure of inorganic compounds. ECS Journal of Solid State Science and Technology, 2013, 2(2): R3001.
[16] WANG S, SONG Z, KONG Y, et al.Crystal field splitting of 4f^n-15d-levels of Ce³+ and Eu²+ in nitride compounds. Journal of Luminescence, 2018, 194: 461.
[17] CHAUDHRY A, BOUTCHKO R, CHOUROU S, et al.First-principles study of luminescence in Eu²+ -doped inorganic scintillators. Physical Review B, 2014, 89(15): 155105.
[18] JIA Y, MIGLIO A, PONCÉ S, et al.First-principles study of the luminescence of Eu²+ -doped phosphors. Physical Review B, 2017, 96(12): 125132.
[19] JI C, CHEN Q, DUAN C-K, et al.Rationalization of near-infrared luminescence of bismuth ions in mixed oxides. Physical Review B, 2024, 109(16): 165152.
[20] GORI M, MONFARDINI G, SCARSELLI F.A new model for earning in graph domains. Proceedings of International Joint Conference on Neural Networks, 2005, DOI: 10.1109/IJCNN.2005.1555942.
[21] JAIN A, ONG S P, HAUTIER G, et al.Commentary: the materials project: a materials genome approach to accelerating materials innovation. APL Materials, 2013, 1(1): 011002.
[22] ZAGORAC D, MÜLLER H, RUEHL S, et al. Recent developments in the inorganic crystal structure database: theoretical crystal structure data and related features. Journal of Applied Crystallography, 2019, 52(5): 918.
[23] XIE T, GROSSMAN J C.Crystal graph convolutional neural networks for an accurate and interpretable prediction of material properties. Physical Review Letters, 2018, 120(14): 145301.
[24] CHEN C, YE W, ZUO Y, et al.Graph networks as a universal machine learning framework for molecules and crystals. Chemistry of Materials, 2019, 31(9): 3564.
[25] LOUIS S-Y, ZHAO Y, NASIRI A, et al.Graph convolutional neural networks with global attention for improved materials property prediction. Physical Chemistry Chemical Physics, 2020, 22(32): 18141.
[26] ZHANG X, ZHOU Z, MING C, et al.GPT-assisted learning of structure-property relationships by graph neural networks: application to rare-earth-doped phosphors. The Journal of Physical Chemistry Letters, 2023, 14(50): 11342.
[27] OPENAI, ACHIAM J, ADLER S, et al.GPT-4 technical report. arXiv, 2024.
[28] ONG S P, RICHARDS W D, JAIN A, et al.Python materials genomics (pymatgen): a robust, open-source python library for materials analysis. Computational Materials Science, 2013, 68: 314.
[29] BLASSE G.Thermal quenching of characteristic fluorescence. The Journal of Chemical Physics, 1969, 51(8): 3529.
[30] DENAULT K A, BRGOCH J, GAULTOIS M W, et al.Consequences of optimal bond valence on structural rigidity and improved luminescence properties in Sr_xBa_2-xSiO₄:Eu²+ orthosilicate phosphors. Chemistry of Materials, 2014, 26(7): 2275.
[31] LI P, YANG Z, WANG Z, et al.Preparation and luminescence characteristics of Sr₃SiO₅:Eu²+ phosphor for white led. Science Bulletin, 2008, 53(7): 974.
[32] DING X, ZHU G, GENG W, et al.Novel blue and green phosphors obtained from K₂ZrSi₃O₉:Eu²+ compounds with different charge compensation ions for leds under near-uv excitation. Journal of Materials Chemistry C, 2015, 3(26): 6676.
[33] YAO S, XUE L, YAN Y.Photoluminescence properties of M₂ZnSi₂O₇: Eu²+ (M=Sr, Ba). Journal of Rare Earths, 2010, 28: 265.
[34] MIDGLEY C M.The crystal structure of dicalcium silicate. Acta Crystallographica, 1952, 5(3): 307.
[35] KIM K-B, KIM Y-I, CHUN H-G, et al.Structural and optical properties of BaMgAl₁₀O₁₇:Eu²+ phosphor. Chemistry of Materials, 2002, 14(12): 5045.
[36] PAN Y, WU M, SU Q.Tailored photoluminescence of YAG:Ce phosphor through various methods. Journal of Physics and Chemistry of Solids, 2004, 65(5): 845.
[37] HIROSAKI N, XIE R-J, KIMOTO K, et al.Characterization and properties of green-emitting-sialon:Eu²+ powder phosphors for white light-emitting diodes. Applied Physics Letters, 2014, 86: 211905.
[38] WATANABE H, YAMANE H, KIJIMA N.Crystal structure and luminescence of Sr_0.99Eu_0.01AlSiN₃. Journal of Solid State Chemistry, 2008, 181(8): 1848.
[39] YANG C-Y, SOM S, DAS S, et al.Synthesis of Sr₂Si₅N₈:Ce³+ phosphors for white leds via efficient chemical vapor deposition. Scientific Reports, 2017, 7(1): 45832.
[40] AULL B F, JENSSEN H P.Impact of ion-host interactions on the 5d -to-4 f spectra of lanthanide rare-earth-metal ions. I. a phenomenological crystal-field model. Physical Review B, 1986, 34(10): 6640.
[41] DORENBOS P.Crystal field splitting of lanthanide 4f^n-15d-levels in inorganic compounds. Journal of Alloys and Compounds, 2002, 341(1/2): 156.
[42] CHO Y, DIERRE B, SEKIGUCHI T, et al.Low-energy cathodoluminescence for (oxy)nitride phosphors. Journal of Visualized Experiments, 2016, (117): 54249.
[43] SMET P F, MOREELS I, HENS Z, et al.Luminescence in sulfides: a rich history and a bright future. Materials, 2010, 3(4): 2834.
[44] MARONGIU D, LAI S, LIU F, et al.Halide double-perovskites: high efficient light emission and beyond. APL Energy, 2023, 1(2): 021501.
[45] XU L-J, LIN X, HE Q, et al.Highly efficient eco-friendly X-ray scintillators based on an organic manganese halide. Nature Communications, 2020, 11(1): 4329.
