The Li–S battery has been under intense scrutiny for over two decades, as it offers the possibility of high gravimetric capacities and theoretical energy densities ranging up to a factor of five beyond conventional Li-ion systems. Herein, we report the feasibility to approach such capacities by creating highly ordered interwoven composites. The conductive mesoporous carbon framework precisely constrains sulphur nanofiller growth within its channels and generates essential electrical contact to the insulating sulphur. The structure provides access to Li⁺ ingress/egress for reactivity with the sulphur, and we speculate that the kinetic inhibition to diffusion within the framework and the sorption properties of the carbon aid in trapping the polysulphides formed during redox. Polymer modification of the carbon surface further provides a chemical gradient that retards diffusion of these large anions out of the electrode, thus facilitating more complete reaction. Reversible capacities up to 1,320 mA h g^-1 are attained. The assembly process is simple and broadly applicable, conceptually providing new opportunities for materials scientists for tailored design that can be extended to many different electrode materials.

Abstract

In this work, a novel nano-sulfur/MWCNTs composite with modified multi-wall carbon nano-tubes (MWCNTs) as sulfur-fixed matrix for Li/S battery is reported. Based on different solubility of sulfur in different solvents, nano-sulfur/MWCNTs composite was prepared by solvents exchange method. The composite was characterized by scanning electron microscopy (SEM) and X-ray diffraction (XRD). The modified MWCNTs are considered that not only acts as a conducting material, but also a matrix for sulfur. The electrochemical performance of the nano-sulfur/MWCNTs composite was tested. The results indicated that nano-sulfur/MWCNTs composite had the specific capacity of 1380 mAh g⁻¹, 1326 mAh g⁻¹ and 1210 mAh g⁻¹ in the initial cycle at 100 mA g⁻¹, 200 mA g⁻¹ and 300 mAh g⁻¹ discharge rates respectively, and remained a reversible capacity of 1020 mAh g⁻¹, 870 mAh g⁻¹ and 810 mAh g⁻¹ after 30 cycles. The electrochemical performances confirm that the modified MWCNTs as sulfur-fixed matrix show better ability than any other carbon in cathode of Li/S batteries that had been reported.

Abstract

Thin-film particles of graphite oxide were synthesized in high yield by the modified Hummers’ method, in which a very long oxidation period was combined with a high purity purification process. The particles obtained had an average thickness of several nanometers and an average width of about 20 μm. The yield was 122 wt% based on the raw graphite and the recovery of carbon was 68%. Moreover, excellent flexibility of the particles was observed for the original particle(s) itself, for the particle in matrix polymer, and for two kinds of secondary conformations (lamination-layer-aggregate and random-shape-aggregate). As generally expected and already observed partially, if the affinity between the particle and the dispersion medium was very high, the thin-film particle extended well, though a local crease or a large bend could be generated. At a medium degree of affinity, the particle slightly bent, and at very low affinity, the particle(s) randomly aggregated.

Graphene is a rapidly rising star on the horizon of materials science and condensed-matter physics. This strictly two-dimensional material exhibits exceptionally high crystal and electronic quality, and, despite its short history, has already revealed a cornucopia of new physics and potential applications, which are briefly discussed here. Whereas one can be certain of the realness of applications only when commercial products appear, graphene no longer requires any further proof of its importance in terms of fundamental physics. Owing to its unusual electronic spectrum, graphene has led to the emergence of a new paradigm of 'relativistic' condensed-matter physics, where quantum relativistic phenomena, some of which are unobservable in high-energy physics, can now be mimicked and tested in table-top experiments. More generally, graphene represents a conceptually new class of materials that are only one atom thick, and, on this basis, offers new inroads into low-dimensional physics that has never ceased to surprise and continues to provide a fertile ground for applications.
